Feature
7 inches colorful touch display
Dry electrochemical.
Working Temperature 10 C–30 C
Storage:2℃-30℃, 8 months
With LIS/HIS Connection
Specification
| Item |
Specification |
| Specification |
P1 |
| Test Principle |
Dry electrochemical |
| Sample Volume |
100UL
|
| Sample Type |
Whole blood （Vein）
|
| Measured parameters |
K+,Na+,Cl-,iCa2+,iMg2+ |
| Working condition |
Temperature 10 C–30 C Relative Humidity 10%
85% (without condensation) Atmosphere pressure 86 kPa 106.6 kPa |
| Printers |
Build-in themal printer |
| Testing time |
5 +/-0.5min |
| Cartridge storage condition and valid time |
2℃-8℃, 8 months |
| Analyzer working condition |
Temperature 18 C–30 C Relative Humidity 25% 75% (without condensation) Atmosphere pressure 86
kPa 106.6 kPa |
| Built-in code scanner |
Yes |
| Built-in printer |
Yes |
| LIS/HIS Connection |
Yes (Ethernet,WIFI) |
| Weight |
240*120mm*110 mm
1.5 0.2kg with battery
7 inches colorful touch display |
Test result Interpretation
1. The test results of this product is for clinical reference only, and should not be used as the sole basis for clinical diagnosis. The clinical management of patients should be considered in combination with their clinical symptoms, medical history, and other laboratory tests.
2. The operating procedures must be strictly followed during operation to ensure correct test results. Any changes to the operating procedures may affect the accuracy of test results.
3. Be sure that blood samples are well mixed after collection to avoid inaccurate analysis of test data resulting from formation of blood clots.
